Safety at Sea for Cruisers – DSC calling policy around the world

by Terry Sparkes and Brunei Bay Radio on 28 Feb 2016

Safety at Sea for Cruisers – DSC calling policy around the world Brunei Bay Radio

Realising there were countless cruisers who were not utilising the DSC capabilities of modern marine radios, Alan Riches of Brunei Radio and Terry Sparkes of 'made simple for cruisers' have developed a list of global group numbers which cruisers can use wherever they are in the world and share the same channel for weather alerts or when help is needed.

This strategy for DSC Group Calling amongst recreational vessels in a NAVAREA region utilises the DSC capabilities of modern marine radios - VHF and HF/SSB - to create a quick response mutual support network.

Group Calling is an established and recommended function of modern DSC capable VHF and HF/SSB marine radios. Group participants simply enter the group call ID into the Group Address Book of their radio. The radio then maintains a constant receive watch for that Group ID. Radios can monitor for multiple group IDs; some up to 100. This allows groups of boats - eg: boat club members, fishing competition participants, yacht race or rally participants, cruising support group, charter yacht fleets, dive or surf charter boats etc - to make immediate DSC initiated contact with any radios in their group which are switched on and in range of the frequency used to initiate the call.

This NAVAREA Group Calling Network is designed to initiate DSC contact with what could be all/any recreational vessels (known or unknown) in range for Non-Distress purposes; if all boats have a DSC capable VHF and/or HF/SSB radio with the local NAVAREA Group Call ID entered and the radio switched on. In HF/SSB radios this system utilises the General Group Calling function built into these DSC radios to more reliably (than voice call) alert nearby vessels to ask for advice, local information, or help. It will work for recreational vessels in large ocean areas, exploring island chains or unfamiliar coastlines when they need to contact a vessel nearby - either an unknown local based vessel or another unknown cruiser - to get advice or assistance.

Vessels need to be in DSC WATCH mode to receive individual and group calls for HF SSB. VHF radio just needs to be turned on.

Cruisers should keep the M802 in DSC Watch Mode to receive calls. Be sure your DSC Watch Mode is scanning simplex. See procedure 'DSC to Simplex for Cruisers' to expand HF DSC calling capability for calling and receiving calls on all six frequencies.

It creates the widest range/most boats DSC Group Call in a tiered DSC Calling system.
For example, a boat in an event/race/rally needing advice/assistance might first make an Individual DSC call to a specific boat or to the event/race/rally control using their individual DSC IDs. If that does not get a suitable response, then DSC call the Group Call DSC ID of their event boats (perhaps 10 to 100 boats). If that does not get a useful response, then try a bigger/broader group such as the Group Call DSC ID of all the boats in their club (perhaps 100 to 300 possible boats) which might be nearby. If that is unsuccessful, send a NAVAREA Group ID call; which should alert any similarly equipped nearby boats (perhaps many hundreds of possible boats) in range.

A NAVAREA Group Call is not a Distress call.
But timely support, advice, spare parts, fuel or a tow, from another nearby mariner could prevent a problem situation, or stop a problem growing into a Distress situation. A DSC Distress call will alert ALL similar marine radios - commercial, recreational, oil and gas platform, man-of-war, ferry, tugs etc - in range with their radios turned on.

This NAVAREA Group Call Network is based on NAVAREA regions.
These existing 21 worldwide maritime regions are used to define S&R responsibility areas, and also define the responsibility areas for creating METAREA forecasts and MSI (Maritime Safety Information) warnings (eg: drifting logs, abandoned vessels, seismic vessel with 5nm long cable, etc.).

Click here map of NAVAREAs of the world

Click here for METAREA forecasts of the world

Click here for links to MSI (Maritime Safety Information) warnings

METAREA forecasts are the important open sea weather and weather warning predictions prepared by a human - not solely a machine - by examining and interpreting the information collected and presented by machines. METAREA forecasts are available for free download - via HF/SSB radio email - by members of the not-for-profit SailMail Association.

MSI warnings are updated daily to provide mariners with safety related information such as navigation lights not working, abandoned vessels, logs or containers fallen off ships in bad weather, military firing exercises or other hazards to navigation, including cable laying or survey ships towing 5nm cables.

An effective instant communications and prompt mutual support network is created in a NAVAREA by all recreational vessels in that region entering that region's Group Call ID (see below) in their radio/s, and maintaining their DSC Capable VHF and/or HF/SSB radios in constant (silent) watch when on-board. All vessels - regardless of their other Group Call IDs - eg: club, race or rally, fishing contest, dive boat or charter fleet etc - will go into an alert state when they receive the NAVAREA Group Call ID.

For example, boats coastal cruising or island hopping can use the NAVAREA Group Call ID to DSC call any nearby boats and then ask by voice for local boats which can help with information on fuel supplies, check-in procedures, waypoints to get into anchorages, etc. And boats at sea can contact any others nearby using the NAVAREA Group Call ID to warn them of hazards (shipping containers, abandoned vessels etc), or request advice with a engine breakdown, a tow, spare part, fuel, dinner recipe etc. This works for VHF and HF/SSB marine radios.
